DZQ-900L External Strip Vacuum Packaging Machine

  • DZQ-900L External Strip Vacuum Packaging Machine
  • DZQ-1000L External Strip Vacuum Packaging Machine
  • DZQ-900L External Strip Vacuum Packaging Machine
  • DZQ-800L External Strip Vacuum Packaging Machine
  • DZQ-700L External Strip Vacuum Packaging Machine
  • DZQ-900L External Strip Vacuum Packaging Machine

  • DZQ-1000L External Strip Vacuum Packaging Machine

  • DZQ-900L External Strip Vacuum Packaging Machine

  • DZQ-800L External Strip Vacuum Packaging Machine

  • DZQ-700L External Strip Vacuum Packaging Machine

  • DZQ-900L External Strip Vacuum Packaging Machine
  • DZQ-1000L External Strip Vacuum Packaging Machine
  • DZQ-900L External Strip Vacuum Packaging Machine
  • DZQ-800L External Strip Vacuum Packaging Machine
  • DZQ-700L External Strip Vacuum Packaging Machine

Description
DZQ-900L external strip vacuum packing equipment will automatically complete the assumed processes of vacuum extraction, aerate as well as sealing, printing, cooling as long as press the lid.
Vacuum sealer machine can be prevented from oxidation, going mould, insects or getting damp, thus the products can be kept fresh in a prolonged storage period.

Application of Vacuum Sealer Machine
DZQ-900L external strip vacuum packing equipment is suitable for meat, rice and traditional Chinese medicine, gas flush and sealing, which avoid oxygenation, keep them fresh.

Technical Characters of Vacuum Sealer Machine
1. TAIWAN AIRTAC pneumatic element ensures the running of pneumatic element to be stable and reliable.
2. The vacuum packing equipment is equipped with heavy-duty mobile caster wheels and sturdy foot with good loading capacity and stability to make it easier when user moving the position.
3. Double-cylinder dual-mouth structure is adopted. The exhaust (charge) speed is fast and the work efficiency is high.
4. The conveyor is suitable for packing big item, and it could reduce the labor’s intensity, making the packing simple and convenient.
5. The vacuum packing equipment is equipped with emergency stop switch. In case of accident, the operator may press the emergency stop switch at any time to terminate the ongoing work program.

Technology Specification of Vacuum Sealer Machine

Model
DZQ-900L/S
DZQ-900L
Machine Dimensions(mm)
1030 × 700 × 1800
1030 × 700 × 1800
Sealer Type
Double Sealing
Single Sealing
Sealer Dimensions(mm)
900 × 10 × 2
900 × 10
Sealer Power Consumption(kW)
1
0.6
Pump Capacity(m3/h)
20
20
Pump Power Consumption(kW)
0.9
0.9
Electrical Requirement(v/Hz)
220/50
220/50
Production Cycle
2-3Time/Min
2-3 Time/Min
Conveyor Adjustment Range (mm)
0-700
0-700
Distance Between Conveyor Working Table and Ground (mm)
370
370
Net Weight(kg)
110
110

    1. DZQ-900L External Strip Vacuum Packaging Machine

      Flexible and reliable packaging equipment systems

    1. DZQ-900L External Strip Vacuum Packaging Machine

      Multiple package sizes, Quick mold switching

    1. DZQ-900L External Strip Vacuum Packaging Machine

      Intelligent control / Precision parts

    1. DZQ-900L External Strip Vacuum Packaging Machine

      Complete Hermetic Seals Every Time

DZQ-900L External Strip Vacuum Packaging Machine
